Uniview ECS-504S-SF-HA Yapay Zeka Analiz Kutusu
Model
ECS-504S-SF-HAUniview ECS-504S-SF-HA yapay zeka analiz kutusu: Supports 4-ch video stream based face snapshot and comparison., Supports generating alarm videos/images and reporting alarm information., Supports H.264 and H.265 video streams., Supports connecting 4 third-party cameras via Onvif and RTSP., Dual Gigabit netwo.
Fiyat ve stok bilgisi alınAynı gün dönüş
Adet ve proje bilginize göre güncel fiyat, stok ve teslim süresini iletelim.
Distribütör garantili
81 ile sevkiyat
Teknik destek
- Supports 4-ch video stream based face snapshot and comparison.
- Supports generating alarm videos/images and reporting alarm information.
- Supports H.264 and H.265 video streams.
- Supports connecting 4 third-party cameras via Onvif and RTSP.
- Dual Gigabit network interfaces enable dual-network IP settings to adapt to different networking environments.
- Supports browser-based access and control.
- Lightweight, fanless structure, flexible deployment, suitable for harsh conditions including dusty, oily, very hot or very cold environments.
Teknik özellikler
Üretici veri sayfasından derlenmiştir; proje öncesi güncel datasheet ile teyit edilmesi önerilir.
Genel 2 satır
| Model | ECS-504S-SF-HA |
|---|---|
| Ürün Tanımı (Üretici) | 4 Channels 1 Hard Disk Intelligent Edge small station |
VCA 1 satır
| Smart | 1, General functions: face detection, Intrusion Detection (support pedestrians, motor vehicles, and nonmotorized vehicles), Overcrowding Detection, Area People Counting, Tripwire People Counting, Preset Marker Detection, Enter Area, Leave Area, Cross Line Detection; 2, Environmental safety: Fire Detection, Fume Detection, Evacuation Route Obstruction, Object Removed, Rat Detection, Dog Detection, Uncovered Soil Detection, Improper Stacking Of Materials, Trash Bin Open Detection, Trash Bin Overfl |
|---|
Özellikler 8 satır
| Yüz Algılama | 4-channel; (Face detection and cannot be enabled simultaneously on the same channel) |
|---|---|
| Face library capacity | 128 face libraries, total 20,000 face images |
| Work clothes library capacity | 8 work clothes libraries, a single storage capacity of 50 images |
| Algorithm self-learning | Support self optimization of some algorithms : Intrusion Detection Cross Line Detection Absence Detection Climbing Detection Long Stay Detection |
| İşletim Sistemi | Linux |
| Operation entry | Web, HDMI, Recommend Web |
| Supported languages | English, Japanese |
| Video input | 4-channel; 2MP-8MP H.265 or H.264 cameras |
Depolama 2 satır
| DDR RAM | 4GB DDR4 |
|---|---|
| Hard disk | 2.5-inch, 128GB SSD included |
Alarm capacity 2 satır
| Alarm image | Max 20,000 alarm images |
|---|---|
| Alarm video | Max 20,000 alarm video clips |
Electrical property 7 satır
| Çalışma Sıcaklığı | -40~70℃ |
|---|---|
| Çalışma Nemi | 5% to 90% (non-condensing) |
| Depolama Sıcaklığı | -40~70℃ |
| Depolama Nemi | 5% to 95% (non-condensing) |
| Güç Tüketimi | ≤20W |
| Ağırlık | ≤1.5KG (with SSD) |
| Boyutlar | 56.3mm(H)×251.3mm(D)×137.7mm(W) |
Harici Arayüz 6 satır
| Ağ Arayüzü | 2 x 10M/100M/1000M adaptive Ethernet interfaces (RJ45) |
|---|---|
| USB Arayüzü | 2 x USB2.0, 1 x USB3.0 |
| Alarm input | 4-ch |
| Alarm output | 4-ch |
| Serial interface | 1 x RS-485 (phoenix connector) |
| Güç Kaynağı | 12 V/2 A |
Data Dock 3 satır
| Websocket mode | √ |
|---|---|
| HTTP/HTTPS mode | √ |
| HTTP/HTTPS live | √ |
Uyumluluk 1 satır
| NDAA Uyumlu | Support |
|---|
Genel bakış
Uniview ECS-504S-SF-HA kullanım alanları ve özellikleri.
Uniview ECS-504S-SF-HA, yapay zeka analiz kutusu modelidir.
Üretici tanımı: 4 Channels 1 Hard Disk Intelligent Edge small station
Öne Çıkan Özellikler
- Supports 4-ch video stream based face snapshot and comparison.
- Supports generating alarm videos/images and reporting alarm information.
- Supports H.264 and H.265 video streams.
- Supports connecting 4 third-party cameras via Onvif and RTSP.
- Dual Gigabit network interfaces enable dual-network IP settings to adapt to different networking environments.
- Supports browser-based access and control.
- Lightweight, fanless structure, flexible deployment, suitable for harsh conditions including dusty, oily, very hot or very cold environments.
Dokümanlar
Veri sayfası ve kullanım kılavuzları.
Datasheet (Teknik Föy) - UNV ECS-504S-SF-HA ECS-504S-SF-HA 4-ch 1-SSD Intelligent Edge Computing Server.pdfPDF · ECS-504S-SF-HA
Kullanım Kılavuzu - UNV-Intelligent Edge Small Station (Algorithm Warehouse) User Manual.pdfPDF · ECS-504S-SF-HA
Hızlı Kurulum Kılavuzu - Quick Guide.pdfPDF · ECS-504S-SF-HA
