Rosslare GC-01 Guard Patrol Data Acquisition Reader Bekçi Tur Okuyucusu
GC-01Rosslare GC-01 bekçi tur okuyucusu: Low battery and memory full alerts by means of vibration, visual, and audio beeps Rosslare’s DigiTool ® guard patrol system leading-edge, high-quality, high-performance for the rigors of guarding, this reader is an handheld reader for metallic numeric large me.
Adet ve proje bilginize göre güncel fiyat, stok ve teslim süresini iletelim.
- Low battery and memory full alerts by means of vibration, visual, and audio beeps Rosslare’s DigiTool ® guard patrol system leading-edge, high-quality, high-performance for the rigors of guarding, this reader is an handh
- Three modes of notification:
- Built-in 360 o LED array for increased visibility of valid iButton reads
- Built-in vibrating motor for tactile read confirmation
- Built-in buzzer for audio read confirmation
- High capacity rechargeable internal 1800 mAh Lithium-ion battery
- Highly rugged and waterproof (meets IP-68 level tests)
- 9600 baud speed uploading/ downloading speed
Teknik özellikler
Üretici veri sayfasından derlenmiştir; proje öncesi güncel datasheet ile teyit edilmesi önerilir.
Elektriksel Özellikler 2 satır
| Çalışma Gerilimi Aralığı | 3.0–3.6 VDC |
|---|---|
| Input Current, Max. | Standby: 6 µA; Maximum: 21 µA |
Çalışma Özellikleri 9 satır
| Uploading/Downloading Speed | 9600 baud speed Real time clock inside saves date and time |
|---|---|
| Time and Date Stamp Memory | Internal Clock Synchronizes with the PC time |
| Number of Reads | Stores up to 8000 reads and time stamps Internal Lithium-Ion 1800 mAh rechargeable battery for six month use |
| Pil | or 300,000 readings |
| Battery Charging Time | Battery charges in three hours from empty to full |
| Buzzer Sounder Indication | Internal sounder for audio verification Four ultra-bright LEDs visual read validation |
| LED Indication | 360 Degree LED viewing angle light-pipe |
| Data Read Speed | 0.1 seconds per read |
| International Safety and EMC | Complies with International Safety and Emissions Regulations |
Çevresel Özellikler 3 satır
| Çalışma Sıcaklığı | -31°C to 63°C (-25°F to 145°F) |
|---|---|
| Çalışma Nemi | 0 to 95% (non-condensing) |
| Kullanım Ortamı | Suitable for outdoor use (IP68 rated) |
Fiziksel Özellikler 4 satır
| Dimensions (H x Diameter) | 175 x 33 mm (6.9 x 1.3 in.) |
|---|---|
| Ağırlık | 225 g (0.5 lb) |
| Construction materials | Polycarbonate and stainless steel housing |
| Guard Patrol Kits | GCK-01 – DigiTool Starter Kit GCK-02 – DigiTool Basic Remote Kit GCK-03 – DigiTool Guard Patrol Upgrade Kit GCK-04 – DigiTool Guard Patrol Basic Kit |
Genel 2 satır
| Sistem Bileşenleri | This product integrates with other DigiTool family of Guard Patrol products: GC-02 Data Acquisition Reader Base GC-03 Data Acquisition Reader Charger GA-01 Location tag, available in several colors GA-02 Event Wallet GA-12 Digital Event Wallet |
|---|---|
| Garanti | 2-Year Limited Product Warranty |
Genel bakış
Rosslare GC-01 kullanım alanları ve özellikleri.
Rosslare’s DigiTool GC-01 reader is part of Rosslare’s DigiTool guard patrol system encompassing a complete range of professional, leading-edge, high-quality, high-performance products for private and public sectors. Designed for the rigors of guarding, this reader is an advanced waterproof, lightweight, and rechargeable handheld reader for metallic numeric Dallas iButton chips. The DigiTool GC-01 packs features such as a large memory, extended rechargeable battery life for ultimate guarding on the go, and rugged housing.
Rosslare’s DigiTool ® GC-01 reader is designed with a focus on high quality and reliability. It is a lightweight hand-held iButton reader intended for trouble free Guard Patrol Touring applications.
The DigiTool ® GC-01 reader collects raw data of guard usage, tours, location tags, user, and event tags. It has three modes of notification for providing confirmation of tag data acquisition. Raw data is downloaded to the GS-01 Reports Lite software, which provide tour management and archival features of the guard patrol system. The software is used to generate reports and analyze data.
The DigiTool ® GC-01 reader has an internal 1800 mAh Lithium-ion rechargeable battery, which can provide over 300,000 reads or 6 months of use before recharging. When used with the GA-06 leather holster, the DigiTool ® GC-01 reader can be worn on a belt for convenient transportation.
Main Features
- Low battery and memory full alerts by means of vibration, visual, and audio beeps Rosslare’s DigiTool ® guard patrol system leading-edge, high-quality, high-performance for the rigors of guarding, this reader is an handheld reader for metallic numeric large memory, extended rechargeable battery housing.
- Three modes of notification:
- Built-in 360 o LED array for increased visibility of valid iButton reads
- Built-in vibrating motor for tactile read confirmation
- Built-in buzzer for audio read confirmation
- High capacity rechargeable internal 1800 mAh Lithium-ion battery
- Highly rugged and waterproof (meets IP-68 level tests)
- 9600 baud speed uploading/ downloading speed
- Flexibility with the option to select models with Dallas iButton ID chip
- Tamper evident seals
- Polycarbonate and carbon-hardened stainless steel casing, ensuring its lightweight, portability, and durability
- High capacity, can hold 8,000 events in non-volatile memory
Nerelerde kullanılır?
Kapı ve turnike geçişlerinde kart, şifre veya parmak iziyle yetkilendirme sağlar.
Tüm özellikler
- Low battery and memory full alerts by means of vibration, visual, and audio beeps Rosslare’s DigiTool ® guard patrol system leading-edge, high-quality, high-performance for the rigors of guarding, this reader is an handh
- Three modes of notification:
- Built-in 360 o LED array for increased visibility of valid iButton reads
- Built-in vibrating motor for tactile read confirmation
- Built-in buzzer for audio read confirmation
- High capacity rechargeable internal 1800 mAh Lithium-ion battery
- Highly rugged and waterproof (meets IP-68 level tests)
- 9600 baud speed uploading/ downloading speed
- Flexibility with the option to select models with Dallas iButton ID chip
- Tamper evident seals
- Polycarbonate and carbon-hardened stainless steel casing, ensuring its lightweight, portability, and durability
- High capacity, can hold 8,000 events in non-volatile memory
Dokümanlar
Veri sayfası ve kullanım kılavuzları.
Sık sorulanlar
GC-01 hakkında kısa yanıtlar.
GC-01 fiyatı ne kadar?
Hızlı teklif
Formu doldurun, GC-01 için fiyat ve teslim süresini iletelim.
