Rosslare SH-12 Press Fit Magnetic Contact Manyetik Kontak

Rosslare's SH-12 is a powerful high-performance indoor magnetic contact, ideal for residential, commercial, and institutional applications. This field-proven reliable magnetic contact is designed for windows and doors and other thin frame applications where an attractive recessed installation is preferred. The unique housing design features a rugged body construction with flexible ribbed sides for quick installations. No glue or screws are needed for mounting; small ribs on the housing hold the contact in place. With the SH-12, you can feel safe and secure. The 11-mm (0.43”) wide gap distance helps prevent false alarms caused by loose fitting doors. Encased in an elegantly designed shell, the SH-12 inconspicuously blends into any environment.

Rosslare’s SH-12 Press Fit Magnetic Contact was designed with a focus on high quality and reliability.

This elegant magnetic contact blends into any environment, keeping a low profile while providing state-of-the-art protection. It is also useful in protecting china cabinets or closets, double-hung windows, and aluminum windows.

Easy to install, the magnetic contact uses no glue or screws to mount. It features an 11-mm (7.16-in.) operating gap and high grade magnets.

The contact and magnet housings are made of flame-retardant ABS plastic. The housing has three ribs that press-fit against the inside of a 9.65-mm (0.38”) diameter mounting hole. The reed switch is protected and held in place by a polyurethane potting material.

indoor magnetic contact, ideal applications. This field-proven windows and doors and other thin recessed installation is preferred. The body construction with flexible glue or screws are needed for the contact in place.

secure. The 11-mm (0.43”) wide gap by loose fitting doors. Encased in an blends into any

Main Features

• Press-fit mount switch, no screws or glue needed Large magnet provides wider gap Rugged body construction with flexible ribbed sides for quick installations Attractive low profile design, with a professional look and feel UV stabilized anti aging virgin polymers High grade magnets 1 Form A (SPST) contact Maximum contact rating, 28 VDC, 1 A 11-mm (0.43”) wide gap Meets or exceeds USA Standard UL 639, Intrusion Detection Units Meets or exceeds CENELEC 50131-2-2 PIR Standard, Security Grade 2, and Environmental Grade 1

Nerelerde kullanılır?

Konut, ofis ve mağazalarda hırsız alarm sisteminin algılama katmanını oluşturur; doğru konumlandırıldığında kör nokta bırakmadan koruma sağlar.
