Hikvision DS-D6055UN-D/S 55 inç Dijital Tabela (Signage)

ModelDS-D6055UN-D/S

Hikvision DS-D6055UN-D/S dijital tabela (signage): Metal shell appearance, slim frame, and all-in-one design, suitable for advertising display at store entrances., Exquisite image, industrial A+ panel, auto-coloring and image-enhancing engine., Frosted glass, anti-glare, clearer images, and wider viewing angle.

Fiyat ve stok bilgisi alınAynı gün dönüş

Adet ve proje bilginize göre güncel fiyat, stok ve teslim süresini iletelim.

Ara WhatsApp

Distribütör garantili

81 ile sevkiyat

Teknik destek

Metal shell appearance, slim frame, and all-in-one design, suitable for advertising display at store entrances.
Exquisite image, industrial A+ panel, auto-coloring and image-enhancing engine.
Frosted glass, anti-glare, clearer images, and wider viewing angles.
Variable materials, static and dynamic materials, including pictures, audio, video, scrolling subtitle, PDF, webpages, live video, number calling, pop-up pictures, etc.
Flexible program schedule, free schedules and district play of multiple materials and variable play modes: play by day, play by week, play by loop, custom play, etc.
Centralized management, remotely control and manage one screen or more screens, such as timed startup/shutdown, quick startup/shutdown, brightness/volume timed adjustment, and screenshot preview, remotely release program
Organization permission, 5-level organization is available for managing materials, programs, terminals, and users, and support creating custom users, allocating permission for users according to user level, and permissio
Multiple security safeguards, 3-level check of materials, programs and schedules to prevent mistake release, encryption of data in storage and transmission to prevent data tampering, and with no default password, users c

Teknik özellikler

Üretici veri sayfasından derlenmiştir; proje öncesi güncel datasheet ile teyit edilmesi önerilir.

Product Model 1 satır

Product Model	DS-D6055UN-D/S

Ekran 17 satır

Ekran Boyutu	55 inch
Color Temperature	10000K
Çözünürlük	2160 × 3840
Active Display Area	1209.6 (H) × 680.4 (V) mm
Piksel Aralığı	0.315 (H) mm × 0.315 (V) mm
Arka Işık	E-LED
Görüş Açısı	178°(H)/178°(V)
Parlaklık	500 cd/m²
Kontrast Oranı	1200:1
Renk Derinliği	10 bit (8 bit + FRC)
Tepki Süresi	8 ms
Color Gamut	72% NTSC
Reliability	7 × 24h
Yenileme Hızı	60 Hz
Haze	25%
Display Ratio	9 : 16
Panel Tipi	IPS

Built-in System 6 satır

İşletim Sistemi	Android 13
İşlemci	Cortex-A55, 4-core, main frequency 1.92 GHz
Bellek	4 GB
Built-in Storage	32 GB EMMC
Video Formatı	AV1, H.265, H.264/AVC, MVC, VP9, AVS2, MPEG4, MPEG2, MPEG1, VP8, MJPEG, H263
Audio Format	MPEG, APE, FLAC, AAC, OGG, AIF, AIFF, ALAW, ALAC

Arayüz 4 satır

Video & Audio Input	HDMI 2.0 (HDCP 2.2) × 1
Video & Audio Output	Speaker (8Ω 5 W) × 2
Ağ Arayüzü	RJ45 × 1, Wi-Fi (2.4G/5G, 802.11 a/b/g/n/ac/ax) × 1, RS232 in × 1, RS232 out × 1
Data Transmission Interface	USB 2.0 × 1, USB 3.0 × 1, BT 5.4 × 1

Güç 3 satır

Giriş Gerilimi	100 to 240 VAC, 50/60 Hz
Standby Consumption	≤ 0.5 W
Güç Tüketimi	108 W (typ), 155 W (max)

Çalışma Ortamı 4 satır

Çalışma Sıcaklığı	0 ℃ to 40 ℃ (32 ℉ to 104 ℉)
Çalışma Nemi	10% to 80% RH (Condensation)
Depolama Sıcaklığı	-20 ℃ to 60 ℃ (-4 ℉ to 140 ℉)
Depolama Nemi	10% to 90% RH (Condensation)

Genel 6 satır

Montaj Tipi	Floor standing
Ürün Boyutları (G × Y × D)	740 (W) mm × 1886 (H) mm × 480 (D) mm（With Stand）; 727 (W) mm × 1776 (H) mm × 63.8 (D) mm（Without Stand）
Package Dimensions (W × H × D)	840 (W) mm × 1895 (H) mm × 155 (D) mm
Net Ağırlık	46.5 kg
Brüt Ağırlık	52 kg
Paket İçeriği	Digital signage × 1, stand × 1, power cord × 1, remote control × 1, user manual × 1, quick start guide × 1, Regulation Compliance and Safety Information × 1, stand fixed with M8 screw × 6, key × 2, foot pad × 4, energy efficiency label × 1, caster wheel × 4, wheel fixed with M4 screw × 16, Base fixed bracket × 2, Base fixed bracket with M4 screw × 4, Expansion screw × 2

Genel bakış

Hikvision DS-D6055UN-D/S kullanım alanları ve özellikleri.

Hikvision DS-D6055UN-D/S, 55 inç ekran sunan bir Dijital Tabela (Signage) modelidir.

55-inch Slim Floor Standing Digital Signage

Metal shell appearance, slim frame, and all-in-one design, suitable for advertising display at store entrances.
Exquisite image, industrial A+ panel, auto-coloring and image-enhancing engine.
Frosted glass, anti-glare, clearer images, and wider viewing angles.
Variable materials, static and dynamic materials, including pictures, audio, video, scrolling subtitle, PDF, webpages, live video, number calling, pop-up pictures, etc.
Flexible program schedule, free schedules and district play of multiple materials and variable play modes: play by day, play by week, play by loop, custom play, etc.
Centralized management, remotely control and manage one screen or more screens, such as timed startup/shutdown, quick startup/shutdown, brightness/volume timed adjustment, and screenshot preview, remotely release programs and updates local (USB) programs.
Organization permission, 5-level organization is available for managing materials, programs, terminals, and users, and support creating custom users, allocating permission for users according to user level, and permission templates.
Multiple security safeguards, 3-level check of materials, programs and schedules to prevent mistake release, encryption of data in storage and transmission to prevent data tampering, and with no default password, users can activate and set initial password to guarantee the password safety.

Dokümanlar

Veri sayfası ve kullanım kılavuzları.

Hızlı Başlangıç KılavuzuPDF · DS-D6055UN-D/S Kullanım KılavuzuPDF · DS-D6055UN-D/S Firmware (V3.4.0000_260723) - indirme sayfasıPDF · DS-D6055UN-D/S

Sık sorulanlar

DS-D6055UN-D/S hakkında kısa yanıtlar.

DS-D6055UN-D/S fiyatı ne kadar?

DS-D6055UN-D/S için fiyat; adet, proje kapsamı ve güncel kura göre değiştiğinden teklif usulüyle verilir. Ürünü teklif listenize ekleyerek veya telefon/WhatsApp hattımızdan ulaşarak aynı iş günü içinde fiyat ve stok bilgisi alabilirsiniz.
