Eaton EC542 Haberleşme / Ağ Geçidi Modülü

Eaton EC542, Addressable Lon Gateway and Adapter ailesine ait haberleşme / ağ geçidi modülü modelidir.

LON NETWORK BOOSTER

Eaton has a range of gateways & adapters for LonWorks communication network protocol, for use with Eaton addressable fire systems. LonWorks adapters (CFSFL01, CFSFL02, EC0232): The CFSFL01 and CFSFL02 allows fibre optic connection to Eaton system network (LonWorks) devices, with the 02 variant extending the system LonWorks up to 15km. The EC0232 Lon to RS232 adapter enables network connection to PC based applications, such as site monitor and site graphics. LonWorks BMS interfaces (EC200, EC210L): Networked Eaton fire control panels cannot normally be used with a building management system (BMS) where binding is required. The EC200 LonWorks BMS interface is an 'add-on' that enables BMS integration. The EC210L should be used with Easicheck panels. LonWorks network addressable booster (EC540): The Lon Network Booster EC540 will interconnect multiple EIA-709 channels. This unit provides up to five ports and routes packets between these ports.

Plug and play Lon network booster

Used for Eaton network extension, the plug and play installation capability of the EC540 range allows network connection without any further configuration. It uses smart switch technology to automatically detect the bit rates of the connected channels, and learn the configuration of the network (domains, subnet / node addresses, group addresses).

Nerelerde kullanılır?

Yangın algılama sisteminde giriş/çıkış kontrolü, loop izolasyonu veya kurulum aksesuarı olarak kullanılır.

Kurulum ve uyumluluk

Yangın algılama sistemleri; Binaların Yangından Korunması Hakkında Yönetmelik ve TS EN 54 standardına uygun olarak projelendirilmeli ve yetkili ekiplerce devreye alınmalıdır.
